YC Series 0.37KW~5KW 50Hz Heavy-Duty Single Phase 220V Copper Electric AC Motors

YC series motors are totally enclosed fan cooled (TEFC)heavy-duty single-phage induction motors. When rated output is 3HP or below,motors and of capacitors,and 4HP or above with capacitor start and run. YC series motors are integrated with up-to-date design,best quality materials construction, and possess the features of pleasant-looking appearance,outstanding performance,easy maintenance. The also concentrate the advantages of high staring torque,smooth turning, low temperature rise,low noise and great overload performance.YC series motors are suitable for powering small type drilling machines and water pimps,especially for family workshops where only single- phase current supply is available.

Operating Conditions：
Ambient temperature: -15℃(5℉)≤0≤40℃(104℉)
Altitude:not exceeding 1000m
Rated voltage: 110V~230V
Rated frequency: 50Hz、60Hz Water Resistance:IP44、IP54
Insulation class:B、F
Cooling method:ICO141
Duty: S1(continuous)
